F4AE0481E*C102
1405.002 HYDRAUL. ACCUMULATOR
| Item | Part number | Description |
|---|---|---|
| 1 | 4893178 | HYDRAULIC CYLINDER ASSY |
| 2 | 4899828 | THREADED UNION |
| 3 | 4899824 | WASHER |
| 4 | 4899804 | VALVE |
| 5 | 4897501 | SENSOR ASSY [UP TO: 189668] |
| 6 | 500372236 | WASHER |
| 7 | 4898654 | VALVE |
| 8 | 504036541 | FUEL LINE ASSY |
| 9 | 504036542 | FUEL LINE ASSY |
| 10 | 4897063 | FUEL LINE ASSY |
| 11 | 4897270 | FASTENING BRACKET |
| 12 | 4897272 | FASTENING BRACKET |
| 13 | 4892980 | SCREW |
| 14 | 4898270 | SCREW |
| 15 | 4899872 | FASTENING BRACKET �6 MM |
| 16 | 4899888 | HEXAGON BOLT M8X105 MM |
