F4AE3481D*R102
1405.004 HYDRAUL. ACCUMULATOR
| Item | Part number | Description |
|---|---|---|
| 1 | 504091065 | HYDRAULIC CYLINDER |
| 2 | 504053874 | HEXAGON BOLT |
| 3 | 4896884 | HEXAGON BOLT |
| 4 | 504088436 | VALVE ASSY |
| 5 | 504123163 | SENSOR |
| 6 | 504323086 | FUEL LINE |
| 7 | 504323096 | FUEL LINE |
| 8 | 504323090 | FUEL LINE |
| 9 | 42553494 | O-RING |
| 10 | 13605711 | SPACER Ø8,5x18 MM |
