F4BE0647A*B100
0710.232 INTAKE MANIFOLD
| Item | Part number | Description |
|---|---|---|
| 1 | 504030789 | INTAKE ELBOW |
| 2 | 4899039 | HEXAGON BOLT M8X1,25X25 MM |
| 3 | 16592324 | HEXAGON BOLT M8X60 MM |
| 4 | 504045225 | GASKET |
| 5 | 504030767 | INTAKE COVER |
| 6 | 4899110 | HEXAGON BOLT |
| 7 | 4895164 | HEXAGON BOLT |
| 8 | 504195798 | FLANGE |
| 9 | 504064367 | PIPE SOCKET |
