| Item |
Part number |
Description |
|
1 |
8015528 |
ELECTRIC MACHINE BCI 184 E 16 50-60HZ |
|
2 |
13449421 |
STUD |
|
3 |
8104707 |
WIRE/CABLE |
|
4 |
4929369 |
WASHER |
|
5 |
16043124 |
SCREW M8X14 MM |
|
6 |
17038421 |
HEXAGON NUT M12 (8) |
|
7 |
16610124 |
HEXAGON BOLT M12X40 MM |
|
8 |
17091374 |
SPRING WASHER Ø12X30X3,0 MM |
|
9 |
17038921 |
NUT M16X2 |
|
10 |
17092374 |
SPRING WASHER Ø16X34X3,6 MM |
|
11 |
17494934 |
WASHER Ø10X18,1X2,2 MM |
|
12 |
15970521 |
HEXAGON BOLT M10X20 MM |
|
13 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
14 |
17038221 |
HEXAGON NUT M10 |
|
15 |
8015486 |
SPACING BAR |
|
16 |
8016047 |
SUPPORT |
|
17 |
16614924 |
SCREW M16X55 |
|
20 |
16614624 |
HEXAGON BOLT M16X40 MM |
|
21 |
4955094 |
RUBBER PAD |
|
22 |
8015168 |
SCREW |
|
23 |
17037821 |
HEXAGON NUT M6X1 |
|
24 |
16606524 |
HEXAGON BOLT M8X70 MM |
|
26 |
8106757 |
EL.MACHINE VOLTAGE REGUL. Stamford |
|
27 |
8092769 |
KIT-GENERATOR Stamford |
