| Item |
Part number |
Description |
|
1 |
8018971 |
ENGINE ACTUATOR ASSY |
|
2 |
8028540 |
RETAINER |
|
3 |
8018673 |
PICK-UP |
|
4 |
8018968 |
ENGINE HARNESS |
|
5 |
17037821 |
HEXAGON NUT M6X1 |
|
6 |
16605734 |
HEXAGON BOLT M8X30 MM |
|
7 |
17040321 |
NUT M6 |
|
8 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
9 |
4934541 |
BRACE/STRUT |
|
10 |
8823236 |
TIE ROD LEFT |
|
11 |
17720114 |
TIE ROD |
|
12 |
8823237 |
TIE ROD |
|
13 |
17152721 |
NUT M6 |
|
14 |
16603824 |
SCREW M6X25 |
|
15 |
17037931 |
HEXAGON NUT M8X1,25 |
|
16 |
17094714 |
WASHER Ø6,4X12 MM |
|
17 |
17088474 |
WASHER Ø6X12 MM |
|
18 |
8025809 |
COVER |
|
19 |
8024920 |
RETAINER |
|
20 |
16603624 |
HEXAGON BOLT M6X16 MM (8.8) |
|
21 |
15004021 |
HEXAGON BOLT M10X1,25X25 MM |
|
22 |
8031536 |
LEVER |
