| Item |
Part number |
Description |
|
1 |
8107202 |
WATER PIPE |
|
2 |
8110256 |
WATER PIPE |
|
3 |
8107731 |
WATER PIPE |
|
4 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
5 |
4864082 |
BANJO BOLT M12X1,5X25 MM |
|
6 |
98434018 |
THREADED UNION |
|
8 |
4927825 |
WATER HOSE |
|
9 |
17764593 |
CLIP Ø20/32 MM |
|
10 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
11 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
12 |
4760312 |
THREADED UNION |
|
14 |
16992340 |
THREADED PLUG M14X1,5 |
|
15 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
|
16 |
98418717 |
WATER HOSE Ø18 MM |
|
17 |
8009640 |
GASKET |
|
18 |
17037931 |
HEXAGON NUT M8X1,25 |
|
19 |
8009696 |
SCREW CONNECTOR M12X1,5X25 |
|
20 |
4835970 |
GASKET |
|
21 |
16605824 |
HEXAGON BOLT M8X35 MM |
|
22 |
4858609 |
WASHER Ø16X22 MM SP=1,5 MM |
|
23 |
16992440 |
THREADED PLUG M16X1,5 |
|
24 |
8107733 |
WATER PIPE |
|
25 |
17742887 |
RUBBER SLEEVE |
|
26 |
17764793 |
CLIP Ø32/50 MM |
|
27 |
4936741 |
CLIP |
|
28 |
8108979 |
RETAINER |
|
30 |
10284460 |
SEAL GASKET Ø10X16 MM |
|
31 |
16992140 |
PLUG M10X1 |
|
32 |
17737687 |
WATER HOSE |
|
33 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
34 |
4788181 |
WATER PIPE |
|
35 |
4760316 |
WATER PIPE |
|
36 |
4853970 |
FLAT ENGINE GASKET |
|
37 |
98418647 |
PIPE SOCKET |
|
39 |
8006084 |
WATER PIPE [from 05-95] |
|
40 |
8006086 |
WATER PIPE [from 05-95] |
|
41 |
16609824 |
HEXAGON BOLT M12X1,75X25 MM |
|
42 |
17091074 |
WASHER Ø12X24X2,8 MM |
|
43 |
8006085 |
WATER PIPE [from 05-95] |
