| Item |
Part number |
Description |
|
1 |
8105900 |
SPACING BAR |
|
2 |
8105559 |
COOLED EXHAUST MANIF. ASSY |
|
3 |
8009455 |
GASKET |
|
4 |
8105604 |
COVER |
|
5 |
8105605 |
EXH. MANIFOLD GKT |
|
6 |
4836361 |
EXH. MANIFOLD GKT |
|
7 |
10730521 |
WASHER Ø10,2 MM |
|
8 |
17038221 |
HEXAGON NUT M10 |
|
9 |
10791021 |
HEXAGON NUT M10X1,25 |
|
10 |
16992211 |
THREADED PLUG M12X1,5 |
|
11 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
12 |
13554830 |
STUD M12X24X150 |
|
13 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
14 |
13552630 |
STUD M12X24X40 |
|
15 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
16 |
13449830 |
STUD M10X1,25X35 MM |
|
17 |
8005196 |
EXHAUST ELBOW |
|
18 |
14282970 |
LOCK PLUG Ø45 MM |
|
19 |
11903140 |
PLUG M10X1,25 |
|
20 |
10260160 |
SEAL GASKET Ø10X14 MM SP=1 MM |
|
21 |
16103621 |
HEXAGON NUT M12X1,25 |
|
22 |
16101521 |
HEXAGON NUT M12 |
|
23 |
10730721 |
WASHER Ø12,2 MM |
|
24 |
4919183 |
FLANGE |
|
25 |
8009606 |
GASKET |
|
26 |
16625734 |
HEXAGON BOLT M8X35 |
|
27 |
17037931 |
HEXAGON NUT M8X1,25 |
