GE8281SRG85.10A80E
3280.027 WATER FILTER

Iveco/FPT WATER FILTER

Item Part number Description
1 1907694 WATER FILTER CARTRIDGE
2 8023354 SUPPORT
3 61316100 VALVE
4 98429281 SEAL GASKET Ø24X31 MM SP=1,5 MM
5 4807730 BREATHER CONN.
6 8027034 WATER PIPE
7 8027033 WATER PIPE
8 16607724 HEXAGON BOLT M10X1,5X30 MM (8.8)
9 17090174 SPRING WASHER Ø10X20 MM
10 4864082 BANJO BOLT M12X1,5X25 MM
11 98474306 WASHER Ø12X20 MM SP=1,9 MM
12 4864083 SCREW CONNECTOR M14X1,5X30 MM
13 4623465 FLANGED SOCKET
14 8027052 RETAINER
15 17090274 WASHER Ø10X20 MM
16 17038221 HEXAGON NUT M10
17 98474308 SEAL GASKET Ø14X22 MM
18 16602324 HEXAGON BOLT M5X25 MM
19 4659218 CLIP
20 4659217 DOWEL
21 4659219 PLATE
