GE8361SRi25.00A70L
A28010010/02 ELECTRONIC GOVERNOR WOODWARD - 24V

Iveco/FPT ELECTRONIC GOVERNOR WOODWARD

Item Part number Description
1 8018344 FUEL LINE [from 07-94]
2 8016444 FUEL LINE [from 07-94]
3 8018345 FUEL LINE [from 07-94]
4 98474308 SEAL GASKET Ø14X22 MM
5 4929627 PIPE SOCKET
6 8017500 ELECTROVALVE [from 04-94]
7 4929626 PIPE SOCKET
8 10182817 LOCK PLUG
9 61320123 SCREW CONNECTOR
10 4934253 RUBBER SLEEVE L=500 MM
11 17764491 CLIP Ø16/25 MM
12 8012659 FUEL LINE
13 8012382 FUEL LINE [up to 07-94]
14 8012381 INJECTION LINE [up to 07-94]
15 8012628 FUEL LINE
16 8108944 ELECTROVALVE
17 10280060 WASHER Ø14X20 MM SP=1,5 MM
