| Item |
Part number |
Description |
|
1 |
8870657 |
GEAR SELECT.SLEEVE |
|
2 |
8870639 |
SHIFT FORK ROD |
|
3 |
16605534 |
HEXAGON BOLT M8X20 MM (10.9) |
|
4 |
17096824 |
WASHER Ø8,40X15 MM |
|
5 |
8859107 |
COVER |
|
6 |
8863475 |
SPRING |
|
7 |
8859111 |
CAP |
|
8 |
8868402 |
CONTROL PISTON |
|
9 |
8859274 |
BUSH |
|
10 |
8863476 |
SPRING |
|
11 |
8870876 |
SHIFT FORK ROD |
|
12 |
16673635 |
HEXAGON BOLT M8X1.25X20 |
|
13 |
8870693 |
GEAR SELECTOR |
|
14 |
8870643 |
SHIFT FORK REVERSE-1ST SPEED |
|
15 |
8870645 |
SHIFT FORK REVERSE-1ST SPEED |
|
16 |
8870640 |
LOCKING PLATE |
|
17 |
8870641 |
LOCKING PLATE |
|
18 |
8859145 |
CAP |
|
19 |
8859232 |
PIN |
|
20 |
16870373 |
CIRCLIP |
|
21 |
17257870 |
DOWEL PIN Ø6 MM |
|
22 |
17261270 |
DOWEL PIN |
|
23 |
8870804 |
PLUG |
|
24 |
8870654 |
UPPER G.BOX COVER |
|
25 |
8863591 |
SPACING BAR |
|
26 |
16988301 |
LOCK PLUG Ø20 MM |
|
27 |
8870646 |
HUB |
|
28 |
13411990 |
BREATHER |
|
29 |
8859231 |
SLIDING SHOE |
|
30 |
8859230 |
SHIFT FORK |
|
31 |
8859313 |
SCREW |
|
32 |
8867468 |
PROTECTION |
|
33 |
40101080 |
SHAFT SEAL |
|
34 |
18138424 |
HEXAGON BOLT M8X20 MM |
|
35 |
8868305 |
COVER |
|
36 |
8870644 |
SHIFT FORK |
