N45MNAM10.01
1050.008 ADDITIONAL MASSES
| Item | Part number | Description |
|---|---|---|
| 1 | 504088120 | SUPPORT ASSY |
| 2 | 4897123 | WASHER |
| 3 | 8093883 | BUSH ASSY |
| 4 | 4897048 | GEAR |
| 5 | 4896947 | GEAR |
| 6 | 4895586 | HEXAGON BOLT |
| 7 | 2830433 | SOCKET-HEAD SCREW |
| 8 | 2831031 | SHAFT |
| 9 | 504088119 | SHAFT |
| 10 | 2831300 | SUPPORT |
| 11 | 16866473 | SPRING LOCKWASHER |
| 12 | 4899109 | HEXAGON BOLT M10X1,5X80 MM |
| 13 | 4897934 | HEXAGON BOLT |
