PU8065SRE10.00A100
0710.104 INTAKE MANIFOLD
| Item | Part number | Description |
|---|---|---|
| 1 | 8112607 | INTAKE ELBOW ASSY |
| 2 | 4851921 | INTAKE ELBOW GASK. |
| 3 | 8006416 | INTAKE ELBOW |
| 4 | 8006418 | HEAT EXCHANG.COVER |
| 5 | 8006421 | O-RING |
| 6 | 8006419 | TUBE STACK |
| 7 | 8006417 | HEAT EXCHANG.COVER |
| 8 | 8006420 | SPACING BAR |
| 10 | 8105277 | SACRIFICAL ANODE Ø14 MM |
| 12 | 4917793 | PLUG M18 |
| 14 | 4858610 | WASHER Ø18X24 MM SP=1,5 MM |
| 15 | 4858606 | GASKET Ø10X14X1 MM |
| 16 | 16992111 | THREADED PLUG M10X1 |
| 17 | 14306621 | SCREW M8X35 |
| 18 | 17094914 | WASHER 8x16 |
| 19 | 17037931 | HEXAGON NUT M8X1,25 |
| 20 | 16729424 | STUD M8X1,25X25 |
| 21 | 16746624 | STUD M8X20 MM (8.8) |
