| Item |
Part number |
Description |
|
1 |
8106612 |
INLINE INJECT.PUMP ASSY W.ALTECNA |
|
4 |
772173 |
FUEL PUMP ASSY WEBER ALTECNA |
|
5 |
771369 |
RETAINER |
|
6 |
4746917 |
THRUST ROD |
|
7 |
15971330 |
HEXAGON BOLT M10X75 MM |
|
8 |
17090274 |
WASHER �10X20 MM |
|
9 |
756671 |
WASHER |
|
10 |
10205720 |
KEY 3X5 MM |
|
11 |
4719841 |
LEVER |
|
12 |
4864082 |
BANJO BOLT M12X1,5X25 MM |
|
13 |
98423793 |
FUEL LINE |
|
14 |
98474306 |
WASHER �12X20 MM SP=1,9 MM |
|
15 |
17291081 |
O-RING �88,49X3,53 MM |
|
16 |
16603824 |
SCREW M6X25 |
|
17 |
17494631 |
SPRING WASHER �5 MM |
|
18 |
16979431 |
NUT M8 |
|
19 |
10902111 |
HEXAGON BOLT M6X14 MM |
|
20 |
17798174 |
SPRING WASHER �6,1X11,8 MM |
|
21 |
17039221 |
NUT M18X1,5 |
|
22 |
10520301 |
WASHER �18,4 MM |
|
23 |
98420453 |
OIL LINE |
|
24 |
98420456 |
OIL LINE |
|
25 |
4864083 |
SCREW CONNECTOR M14X1,5X30 MM |
|
26 |
4864080 |
SCREW CONNECTOR M10X1,25 |
|
27 |
4864079 |
SCREW CONNECTOR M10X1 |
|
28 |
98474308 |
SEAL GASKET �14X22 MM |
|
29 |
98474305 |
WASHER �10X17 MM SP=2,3 |
|
30 |
9981532 |
FUEL PUMP BOSCH |
|
31 |
4787258 |
INLINE INJECT.PUMP ASSY BOSCH |
