S30ENTM23.10
A40050528 GAS-WATER MIXER WITH STERN OUTLET
| Item | Part number | Description |
|---|---|---|
| 1 | 8050612 | SILENCER |
| 2 | 8046438 | EXHAUST PIPE |
| 3 | 8050484 | WATER HOSE |
| 4 | 8046439 | CONNECTOR SLEEVE |
| 5 | 8046440 | CLIP |
| 6 | 8111053 | CLIP |
| 7 | 17764892 | PIPE CLIP Ø40-60 MM |
| 8 | 8050483 | EXHAUST PIPE |
| 9 | 16605424 | SCREW M8X16 MM (8.8) |
| 10 | 17094814 | WASHER |
| 11 | 8042067 | FLAT ENGINE GASKET |
